Solar Mounting System
Aluminum and galvanized steel mounting structures.
- Aluminum & steel optionsAnodized aluminum or hot-dip galvanized steel
- Engineered for wind/snowStructural calculations and stow loads available
- Fast installationPre-assembled clamps and rails reduce labor time
- 10-year warrantyCorrosion-resistant hardware included
| Material | AL6005 / HDG |
|---|---|
| Type | Roof / Ground |
| Wind load | Up to 60m/s |
| Custom | Available |
Product Introduction
Our solar mounting system provides a complete structural solution for rooftop, ground, and carport PV installations. Rails, clamps, brackets, and fasteners are engineered to withstand local wind and snow loads while minimizing installation time.
Aluminum rail kits are ideal for residential and commercial rooftops due to their light weight and corrosion resistance. Steel pile-driven or ballasted systems are available for large ground-mount arrays and solar carports.
Each system is supplied with ballast or foundation recommendations, rail splices, mid/end clamps, and grounding hardware to ensure code-compliant, long-lasting arrays.
Main Features
- Anodized aluminum 6005-T5 rail profile
- Hot-dip galvanized steel posts and piles
- Stainless-steel fasteners with anti-corrosion coating
- Adjustable tilt angles from 5° to 45°
- Compatible with framed modules from 30mm to 50mm
- PE/PVC rubber pad protection for metal roofs
Specifications
| Model | Application | Material | Rail Length | Tilt Angle | Module Frame |
|---|---|---|---|---|---|
| EP-RMT | Tin/metal roof | Al 6005-T5 | 4.2 m | 5-30° | 30-50 mm |
| EP-RMTB | Tile roof | Al 6005-T5 | 4.2 m | Roof pitch | 30-50 mm |
| EP-RMF | Flat roof | Al/HDG steel | 4.2 m | 10-30° | 30-50 mm |
| EP-RMG | Ground mount | HDG steel | 6.0 m | 10-45° | 30-50 mm |
| EP-RMC | Carport | HDG steel | Custom | 5-15° | 30-50 mm |
Item Details
Rooftop Systems
- Rail options
- L-foot, standing-seam clamp, tile hook, and trapezoidal clamp.
- Load sharing
- Distributed load design protects roof membrane.
- Penetration-free
- Ballasted flat-roof option available for suitable structures.
Ground & Carport
- Foundation
- Driven piles, concrete piers, or ballasted foundations.
- Corrosion
- HDG steel ≥65µm zinc thickness for 25-year life.
- Carport benefit
- Generates power while providing vehicle shade and shelter.
Engineering Support
- Static calculation
- Wind and snow load reports per Eurocode/ASCE.
- Layout drawings
- Panel placement and foundation plan provided.
- Installation manual
- Step-by-step guide with torque specifications.
Core Application Scenarios
- 01Residential rooftop arrays
- 02Commercial flat-roof systems
- 03Ground-mount solar farms
- 04Solar carports and canopies
Get a Quote for This Product
Tell us your required quantity and destination port — we will send a detailed quotation within 24 hours.
