Flexible Solar Module
Lightweight flexible panel for curved and mobile applications.
- ConstructionETFE surface, frameless, no glass
- Power Range50 W – 200 W
- Max Bend RadiusUp to 30° curvature
- WeightFrom 1.1 kg (about 80% lighter)
| Power | 50W – 300W |
|---|---|
| Type | Flexible |
| Feature | Lightweight |
| Application | Curved / mobile |
Product Introduction
The flexible module replaces glass and aluminium with an ETFE (ethylene tetrafluoroethylene) front surface laminated onto a flexible polymer backing. There is no frame and no rigid glass, so the panel bends to roughly 30° of curvature and weighs a fraction of a conventional module — 200 W comes in at about 3.2 kg versus 21 kg for a framed panel of similar output.
ETFE is the key material choice. Compared with the cheaper PET used on entry-level flexible panels, ETFE has a self-cleaning micro-textured surface, far higher UV stability and light transmittance above 95%, which is why it holds output for years instead of yellowing and delaminating after a season or two in strong sun.
Mounting is adhesive, eyelet or hook-and-loop rather than clamped rails, so the panel can follow the curved roof of a motorhome, the deck of a yacht or a tent canopy. One design caution: without an air gap the panel runs hotter than a framed module, so leave ventilation behind it where the surface allows, and expect somewhat lower efficiency per square metre than rigid glass panels.
Main Features
- ETFE front surface: >95% light transmittance, self-cleaning micro-texture, excellent long-term UV and weather stability.
- Bends to approximately 30° curvature — mounts on curved RV roofs, boat decks, tents and irregular surfaces.
- Extremely light and thin: about 80% lighter than a framed glass module, ideal where roof load capacity is limited.
- Frameless and glass-free, so there is nothing to shatter — safe for mobile and marine use.
- Flexible mounting: adhesive bonding, brass eyelets or hook-and-loop, with no rails or roof penetrations needed.
- IP67 junction box with MC4 output; salt-spray resistant for marine environments.
Specifications
| Model | Pmax (W) | Vmp (V) | Imp (A) | Voc (V) | Isc (A) | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| EP-FX-050 | 50 | 18.0 | 2.78 | 21.6 | 2.98 | 630 × 540 × 2.5 | 1.1 |
| EP-FX-100 | 100 | 18.2 | 5.50 | 21.8 | 5.85 | 1050 × 540 × 2.5 | 1.9 |
| EP-FX-150 | 150 | 18.4 | 8.15 | 22.0 | 8.65 | 1350 × 680 × 2.5 | 2.6 |
| EP-FX-200 | 200 | 18.6 | 10.75 | 22.2 | 11.40 | 1580 × 810 × 2.5 | 3.2 |
Item Details
Cell & Electrical Data (STC)
- Cell Type
- Monocrystalline high-efficiency cells
- Front Surface
- ETFE, light transmittance > 95%
- Maximum System Voltage
- 600 V DC
- Junction Box
- IP67 rated with MC4 output cables
- Power Tolerance
- 0 ~ +3%
- System Compatibility
- 12 V / 24 V battery systems via MPPT controller
Mechanical & Mounting
- Thickness
- 2.5 mm (typical)
- Maximum Curvature
- Approximately 30°
- Frame
- None — frameless flexible laminate
- Mounting Options
- Structural adhesive / brass eyelets / hook-and-loop
- Backing
- Flexible polymer composite
- Ventilation Note
- Leave an air gap where possible; panel runs hotter than framed types
Environment, Ratings & Warranty
- Operating Temperature Range
- −20 °C ~ +85 °C
- Temperature Coefficient of Pmax
- −0.38 %/°C
- Salt-Spray Resistance
- Yes — suitable for marine use
- Water Resistance
- IP67 junction box
- Product Warranty
- 3 years
- Power Output Warranty
- 10 years, ≥ 80% output
Core Application Scenarios
- 01Motorhomes, caravans and camper vans with curved or load-limited roofs
- 02Yachts, sailboats and marine decks where weight and salt resistance matter
- 03Tents, awnings, backpacks and portable off-grid power kits
- 04Curved architectural surfaces and temporary installations where rails cannot be fixed
