Solar Panel

N-type 182 Mono-Facial Solar Module

N-type 182mm mono-facial high-efficiency module.

Cell TechnologyN-Type TOPCon, 182mm wafer
Power Range555 W – 580 W
Module EfficiencyUp to 22.45%
Warranty15-year product / 30-year power

Key Specifications
Power	550W – 600W
Cell Type	N-type 182 mono
Efficiency	Up to 22.5%
Warranty	25 years

Get a Quote for This Product Ask a Question

Product Introduction

This module is built on N-type TOPCon (Tunnel Oxide Passivated Contact) cell technology using 182mm silicon wafers, arranged as 144 half-cut cells in a 72-cell layout. Compared with conventional P-type PERC cells, the N-type substrate has no boron–oxygen complex, which virtually eliminates light-induced degradation (LID) and dramatically reduces potential-induced degradation (PID).

The ultra-thin tunnel oxide layer on the rear surface passivates the contact interface, lifting open-circuit voltage and cutting recombination losses. The result is a higher module efficiency, a gentler temperature coefficient of −0.30%/°C and a markedly better low-light response — so the array keeps producing at dawn, dusk and under overcast skies when P-type modules have already dropped off.

A mono-facial white backsheet construction keeps weight down to 27.5 kg, making this the practical choice for pitched roofs, sheet-metal industrial roofs and any mounting structure where rear-side gain cannot be harvested anyway.

Main Features

N-Type TOPCon cells deliver first-year degradation of only 1% and annual degradation of 0.4%, guaranteeing ≥ 87.4% output after 30 years.
Temperature coefficient of Pmax at −0.30%/°C — roughly 15% less heat loss than P-type PERC, giving higher real-world yield in hot climates.
Half-cut cell design with a 12-busbar layout lowers internal resistive loss and improves shading tolerance.
Excellent low-irradiance performance: stable output at 200 W/m², extending effective generating hours per day.
Anodised aluminium alloy frame with 5400 Pa snow load and 2400 Pa wind load rating; IP68 junction box with three bypass diodes.
Certified to IEC 61215 / IEC 61730, plus salt-mist and ammonia resistance for coastal and agricultural sites.

Specifications

Model	Pmax (W)	Efficiency (%)	Vmp (V)	Imp (A)	Voc (V)	Isc (A)
EP-NT182-555	555	21.48	41.85	13.26	50.15	13.98
EP-NT182-560	560	21.67	42.05	13.32	50.35	14.04
EP-NT182-565	565	21.87	42.25	13.38	50.55	14.10
EP-NT182-570	570	22.06	42.45	13.43	50.75	14.16
EP-NT182-575	575	22.25	42.65	13.48	50.95	14.22
EP-NT182-580	580	22.45	42.85	13.54	51.15	14.28

Item Details

Cell & Electrical Data (STC: 1000 W/m², AM1.5, 25 °C)

Cell Type: N-Type monocrystalline TOPCon
Cell Size / Layout: 182mm × 91mm, 144 half-cut cells (72-cell format)
Busbars: 12 BB (multi-busbar low-resistance design)
Maximum System Voltage: 1500 V DC (IEC)
Maximum Series Fuse Rating: 25 A
Power Tolerance: 0 ~ +5 W (positive only)

Mechanical Parameters

Dimensions (L × W × H): 2278 × 1134 × 30 mm
Weight: 27.5 kg
Front Glass: 3.2mm anti-reflective coated tempered glass
Backsheet: White composite backsheet (mono-facial)
Frame: Anodised aluminium alloy
Junction Box: IP68 rated, 3 bypass diodes
Cable / Connector: 4mm², 300mm (+) / 300mm (−); MC4 compatible

Temperature, Ratings & Warranty

Temperature Coefficient of Pmax: −0.30 %/°C
Temperature Coefficient of Voc: −0.25 %/°C
Temperature Coefficient of Isc: +0.045 %/°C
Operating Temperature Range: −40 °C ~ +85 °C
Mechanical Load (Front / Rear): 5400 Pa / 2400 Pa
Product Warranty: 15 years
Power Output Warranty: 30 years linear, ≥ 87.4% at year 30

Core Application Scenarios

01Residential pitched roofs and rooftop retrofits where light weight matters
02Commercial and industrial sheet-metal roofs with no usable rear-side reflection
03Utility-scale ground mount projects prioritising the lowest LCOE per watt
04Hot-climate installations in the Middle East, Africa and Southeast Asia where the low temperature coefficient pays back
